Aiphone JPW-BA, Long Distance Adaptor
Aiphone JPW-BA, Long Distance Adaptor
Part Number:
AIP896
Need help? Contact Us Now!
Trade pricing available via login.
View full details
Aiphone JPW-BA, Long Distance Adaptor
JPW-BA Long Distance Adaptor.
Firstly, The JPW-BA is a long distance / CCTV adaptor for the JP Series. In addition, used as a long distance adaptor, it will allow the distance to the video door station to be extended to up to 980’.
Secondly, used as a CCTV adaptor, and in addition allow for an analog CCTV camera to be connected in conjunction with the GT-D audio door station. Equally important,The JPW-BA will surface mount using the mounting holes or with the W-DIN11 mounting rail.
Lastly, It is powered with a PS-2420UL. Each Aiphone JPW-BA is used for one feature only. For multiple cameras or if both features are required, add the appropriate number of adaptors.
Features:
- Extends wiring distance from door stations to master stations up to 980′ max
- Moreover, requires low capacitance Aiphone wire #851602 or #851602DBW
- Furthermore, CCTV Adaptor that allows for an analog CCTV camera to be connected in conjunction with the GT-D audio door station
Specifications:
- Capacity: One adaptor unit for each video door station located beyond the standard specified wire distance
- Mounting: Din rail (sold separately)
- Wire Type: 2-cond., low cap, PE, solid, non-shielded - use Aiphone #851602 or #851602DBW (direct burial) BNC / Coax for CCTV camera
- Wire Distance: Adaptor to Door Station: 650' Adaptor to Master Station: 330'
- Temperature Rating: 32-104°F (0-40°C)
- Dimensions: 4-5/16" H x 4-7/8" W x 2-7/16" D
