Elsema, FMT15108E 8 Ch Fixed Location 151MHz

ELSEMA FMT15108E 8 Ch Fixed Location 151MHz

The FMT151 series gives a controlled range of up to 5km. The controlled operation can be any electronic or electrical operated device when used with the FMR151. series of receivers. Users can activate the channels by connecting reed switches, toggle switches, push buttons, or any normally open (NO) contact to the screw-type terminals. The input should be voltage free contact closure only. The 151MHz transmitter is suitable for industrial applications where you would have a high level of electrical interference. Man-made or electrical interference does not affect this transmitter. This makes FMT151 an ideal choice for use in heavy industrial environment.

The transmitter sends each channel individually to the receiver, enabling simultaneous channel transmission for up to 8 different functions at once. Each channel can operate any FMR151 series receivers making it possible to transmit each channel to different single channel receivers or to multi channel receivers. The transmitter uses a specially programmed micro-controller which ensures the highest reliability, low standby current consumption and greater flexibility. External supply connection and SO239 antenna socket is provided with the transmitter.

Features:

• Long rangeup to 5km.
• Not affected by Natural or man-made electrical interference
• Specially programmed micro-controller
• Simultaneous channel transmission is possible; i.e. more than one channel can be activated at a time.

Applications

• Pump Control
• Long distance panic button
• On/Off applications in agricultural devices
• Security alarm
• Basic Telemetry eg. Water level indication
