The Potter HUSD-15BL Dual Action Hold-Up Switch features a dual-button design that prevents accidental activation by requiring simultaneous presses. Its latching operation ensures the alarm remains active until manually reset. This reliable switch enhances security in various settings, making it an ideal choice for businesses concerned about safety.
The HUSD-15BL is a Form C (SPDT) dual-button hold-up switch that generates an alarm only when both buttons are pressed simultaneously, preventing accidental activation. Additionally, it features a latching operation, ensuring the alarm remains active once triggered.
The housing of this series is specially designed with a status window, red (alarm) and blue (armed), to verify the switch condition. The housing mounting screw is concealed to provide additional tampering protection. The built-in UL approved microswitch design generates an alarm condition when the cover is removed or damaged. The terminal strip consists of three wire ports that provide a firm and secure wiring installation.
Features:
- Latching operation
- Dual button activation to eliminate accidental triggering
- SPDT transfer contact for supervised loop
- Terminal strip with three wire terminals
- Tamper protected switch mechanism using UL listed microswitch
- Concealed mounting screw
- Status window indicator
- White plastic case housing
Technical Specifications:
- Mechanism Type: Latching
- Contact Type: SPDT N.O./N.C.
- Contact Rating: 0.4A @ 125VDC, 5A @ 30VDC, 5A @ 125VAC
- Overall Stroke: 3mm
- Overall Force: 10.5 - 14 ounce
- Operation Method: Dual button
- Operating Temperature Range: 32F to 120F (0C to 49C)
