Potter, HUSD-15BM DBL Self Resetting Hold-Up Switch
Potter, HUSD-15BM DBL Self Resetting Hold-Up Switch
Potter, HUSD-15BM DBL Self Resetting Hold-Up Switch
The Potter, HUSD-15BM DBL Self-Resetting Hold-Up Switch offers a reliable solution for triggering emergency alerts. Designed for security applications, it provides instant activation during a hold-up situation and features a self-resetting mechanism for continuous use. Additionally, its compact design ensures easy installation in various environments, enhancing overall safety.
The Potter, HUSD-15BM DBL Self Resetting Hold-Up Switch, generates an alarm only when both buttons are pressed simultaneously, preventing accidental activation. It features a latching operation, meaning the switch remains active once triggered. Additionally, its dual-button design ensures added security and reliability in emergency situations.
The housing of this series is specially designed with a status window, red (alarm) and blue (armed), to verify the switch condition. The housing mounting screw is concealed to provide additional tampering protection. The built-in UL approved microswitch design generates an alarm condition when the cover is removed or damaged. The terminal strip consists of three wire ports that provide a firm and secure wiring installation.
Features of Dual Action Hold-up Switch:
- Latching operation
- Dual button activation to eliminate accidental triggering
- SPDT transfer contact for supervised loop
- Terminal strip with three wire terminals
- Tamper protected switch mechanism using UL listed microswitch
- Concealed mounting screw
- Status window indicator
- White plastic case housing
Technical Specifications:
- Mechanism Type: Latching
- Contact Type: SPDT N.O./N.C.
- Contact Rating: 0.4A @ 125VDC, 5A @ 30VDC, 5A @ 125VAC
- Overall Stroke: 3mm
- Overall Force: 10.5 - 14 ounce
- Operation Method: Dual button
- Operating Temperature Range: 32F to 120F (0C to 49C)
