Rosslare, AC-F44 Standalone Keypad and Proximity Reader

Rosslare, AC-F44 Standalone Keypad and Proximity Reader

Rosslare’s standalone backlit PIN + Proximity controller is used for indoor and outdoor systems where PIN and / proximity card credentials are required. This durable model can be easily programmed with up to 500 users, on a single door.

Main Features:

• 500 Users
• Code search feature for easy maintenance of user codes
• Three user levels:
  – Normal – Requires single PIN code or Proximity card
  – Secure – Requires PIN code + Proximity card
   – Master User
• Three access levels:
• Normal
• Bypass
• Secure
• Integrated keypad for PIN entry
• Programmable PIN code length of 4 to 8-digits
• Integrated proximity card reader
• Programmable Backlight and active LED control
• Internal buzzer
• Vandal-proof screw (special tool supplied)
• Supplied with a mounting template for easy installation
• Powered either by a transformer (AC) or regulated power supply (DC)

PROFESSIONAL GRADE FEATURES

•  water-resistant and UV-resistant
• Internal buzzer
• Two inputs: REX and Auxiliary
• Two Forms C, 2 Amp outputs: Lock Strike and Auxiliary
• Two tri-coloured status/programming LEDs
• Ten programmable auxiliary behaviour modes including Door Ajar, Forced Door, Alarm Shunt, Door Monitor, and LED control
• Programmable Bell, chime, siren and strobe features available with BL-D40
• Programmable siren time (with BL-D40)
• Built-in case and optical back tamper
• Lockout feature on wrong entries (Keypad / Card Tamper)
• Programmable lock strike release time
