Secukey VControl 2 Video Intercom & Access Control with Tuya WiFi - Oval
Secukey VControl 2 Video Intercom & Access Control with Tuya WiFi - Oval
Secukey
Vcontrol 2 WIFI Video Intercom Access
Tuya WiFi Intercom
- 2.4G WiFi connection,
- Android and iOS available
- Full duplex voice intercom
- 2MP+wide angle camera and night vision
- Support TF card with unlimited capacity
- Support motion detection, playback, take picture/video, unlock remotely
Access Control
- Touch key with one relay, 1000 users (988 common+2 panic+10 visitor)
- PIN Length: 4~6 digits
- EM card, Mifare card optional
- Wiegand 26~44 bits in put & output
- Can be used as Wiegand reader with LED & buzzer
- User data can be transferred
- 2 devices can be interlocked for 2 doors
Applications ofSecukey VControl 2 Video Intercom & Access Control with Tuya WiFi - Oval
- Residential Security: The system serves as an ideal solution for homeowners, enhancing security by enabling residents to see and communicate with visitors before granting access.
- Commercial Use: Additionally, it is perfect for offices and commercial buildings, where it helps manage entry points efficiently and ensures only authorized personnel gain access.
- Multi-Family Units: In apartment complexes, this system allows multiple tenants to monitor their entrances and control access effectively.
- Remote Monitoring: Thanks to Tuya WiFi integration, users can access the system remotely via a smartphone app, making it convenient to monitor their property from anywhere.
- Visitor Management: The video intercom feature facilitates effective visitor screening, allowing users to interact with guests and delivery personnel before granting entry.
- Integration with Security Systems: Moreover, the device easily integrates with existing security systems, enhancing overall security measures in both residential and commercial properties.
- Child and Pet Safety: This system empowers parents to monitor who enters their home, adding an extra layer of safety for children and pets.
- Easy Installation: Lastly, the user-friendly design allows for quick installation in various settings, ensuring seamless integration with existing infrastructures.
- Emergency Response: The system also facilitates quick communication with emergency services in case of suspicious activity or emergencies.
| Video Intercom | Network | 2.4GWiFi connection |
| Pixel | 2.0Mpx (1080P) | |
| Visual Angle | Horizontal 140° wide angle | |
| Night Vision | IR-CUT (Colorful at daytime, black and white at night) | |
| Extended Memory | TF card with unlimited capacity | |
| Intercom | Full duplex voice intercom | |
| Other Functions | Motion detection; Playback; Take picture/video; Unlock remotely | |
| Access Control |
User Capacity Common User |
1000 988 10 |
| PIN Length | 4~6 digits | |
| ProximityCard Reader Radio Technlogy Read Range |
EM or Mifare 125KHz/13.56MHz 2~6cm |
|
| Wiring Connections | Relay output, exit button, alarm, door contact, Wiegand input/output | |
|
Relay Adjustable Relay Output Time Lock Output Load |
One (NO, NC, Common) 0~99 Seconds (5 seconds default) 2 Amp Maximum |
|
|
Wiegand Interface PIN Output |
EM card version: Wiegand 26~44 bits input & output(Factory default: Wiegand 26bits) Mifare card version:Wiegand 26~44 bits input & output(Factory default: Wiegand 34bits) 4 bits,8bits (ASCII),10 digits Virtual Number(Factory default:4bits) |
|
| Electric |
Operating Voltage Idle Current |
DC 12V ¢€°¤ 150mA |
|
Environment Operating Temperature Operating Humidity |
Indoor -20°C ~ 60°C (-4°F ~ 140°F) 0%RH ~ 86%RH |
|
|
Physical Color Dimensions Unit Weight Shipping Weight |
Zinc-Alloy Sliver & Black L149x W70x H25(mm) 400g 510g |
The device is Touch key Access Controller with WiFi-enabled Intercom. People can install the APP for intercom with their smart phone,
and program the access controller by touch key. It is compatible with both iOS (7.0 above) and Android (4.3 above).
